It is manufactured from high-strength EN AW-6082 T6 aviation aluminum alloy. Main tube Φ50×2mm, diagonal brace tube Φ20×2mm, square outer profile size 290×290mm, a heavy-duty square aluminium truss.
-
- EN
-
Constructed from robust EN AW‑6082 T6 aluminum with a 290 mm profile, the F34 circle segment (e.g. 2 m diameter, 180° arc) offers seamless modularity across F34 systems. Ideal for stage hangers, exhibition rings, and architectural features, it ensures smooth curved designs, efficient setup with conical connectors, and consistent load performance.
The F34 Square Circular Segment excels in creating visually striking curved truss installations that balance aesthetics with structural integrity. It seamlessly integrates with F34 straight and corner components to deliver adaptable, reliable solutions for dynamic event sets or architectural designs.
| Length (L) | Circle |
| Angle (A) | Various diameters |
| Span(m) | 2m | 4m | 6m | 8m | 10m | 12m |
| Distrib.Load(kg/m) | 1422 | 493 | 223 | 127 | 79 | 51 |
| Deflection(mm) | 2.4 | 13.7 | 31.8 | 58 | 90.5 | 126.4 |
| Point Load(kg) | 1919 | 987 | 670 | 507 | 394 | 308 |
| Deflection(mm) | 2.6 | 11 | 25.6 | 46.9 | 73.6 | 103.6 |
Made of high-strength materials, lightweight, easy to assemble and stable in load-bearing. Suitable for exhibitions, stages, advertising, etc. Modular design for flexible size adjustment, wind-resistant and anti-deformation, practical and economical.
Welcome to our FAQ, we are so happy to have you here and as a client.
We have tried to answer the most common questions.
It is manufactured from high-strength EN AW-6082 T6 aviation aluminum alloy. Main tube Φ50×2mm, diagonal brace tube Φ20×2mm, square outer profile size 290×290mm, a heavy-duty square aluminium truss.
Available standard lengths: 0.25m, 0.5m, 0.75m, 1m, 1.5m, 2m, 2.5m, 3m, 3.5m, 4m, 4.5m. Unit weight ranges from 2.56kg to 22.76kg with heavy-duty high-strength design.
It is widely applied for large performance stages, music festival lighting & sound rigs, large exhibition booths, stadium hanging projects and commercial touring shows. Its maximum safe span reaches 12 meters with outstanding load capacity, complying with international safety standards as the core profile of professional event aluminum truss system.
It supports full series of matching fittings including corners, T-joints, cross connectors, curved truss F34-C and base plate F34-BP, such as F34-C19, F34-C20, F34-C21, F34-T35, F34-C60 and more. Equipped with original spigot connectors, it can be freely spliced to construct complete modular aluminium truss system.
