Pre-rig truss-5-A

Combined with tiger-claw light hooks for fixation, Enables the random transfer and quick installation of lighting equipment.

At the same time, integrates lighting fixture loading, storage and convenient transportation functions, The plug-in installation method further improves the construction efficiency



Main Tubeφ50×4mm
Vice Tubeφ50×3mm
Braceφ25×3mm
Spec610×358×2400mm
Aluminum AlloyEN AW-6082 T6



Advantages of Pre-rig truss-5-A

Aviation Aluminium Aviation Aluminium
Aviation Aluminium
EN AW-6082 T6 alloy, light weight, high load capacity, anti-rust & wear-resistant
Dual Size Options Dual Size Options
Dual Size Options
Short PR3 & long PR5 to fit different quantities of lighting fixtures
Pre-Rig Time Saving Pre-Rig Time Saving
Pre-Rig Time Saving
Pre-install lights for full-frame transport, drastically reduce on-site setup time
Modular Split Design Modular Split Design
Modular Split Design
Separable truss frame & wheel base for compact storage & delivery
Wheeled Mobility Wheeled Mobility
Wheeled Mobility
Silent universal casters for easy single-person moving across venues
Truss System Compatibility Truss System Compatibility
Truss System Compatibility
Professional truss manufacturers support truss wholesale with full aluminium truss matching

Pre-rig truss-5-A Details

As a folding truss system, this solution is built on a multi truss structure and functions as a stage lighting truss. Combined with the truss lifting system, it enables fast positioning and efficient installation of lighting equipment. The integrated foldable leg design, together with tiger-c law light hooks for fixation, allows random transfer and quick installation of lighting equipment.

Pre-rig truss-5-A_1.jpg

Multi-Functional Use: At the same time, it integrates lighting fixture loading, storage and convenient transportation functions. The plug-in installation method further improves the construction efficiency.

Stage Light Array Construction Solution: Matched with the dedicated lifting head for Pre-rig Truss, it forms a faster stage light array construction solution as a whole. Suitable for various tour performances, small concerts, music festivals, etc. Projects that require quick transfer and construction of lighting equipment.

Products Associated with Pre-rig truss-5-A

Multi-Purpose Cart
/
Lights Pole
/
C-Body Mobile Light Array Truss
Multi-Purpose Cart
C-Body Mobile Light Array Truss
600mm×1000mmmm
New Upgrade Extended C-Body Moving Light Truss
Multi-Purpose Cart
New Upgrade Extended C-Body Moving Light Truss
600mm×800mmmm
Pre-Rig Truss-3
Multi-Purpose Cart
Pre-Rig Truss-3
609mm×356mm×1425mm
CP Rack
Multi-Purpose Cart
CP Rack
1524mm×609mm×356 mm
Light Porter
Multi-Purpose Cart
Light Porter
1524 × 609 × 356 mm
Multi-Purpose Cart-1
Multi-Purpose Cart
Multi-Purpose Cart-1
1600mm×800mm×1930 mm
Multi-Purpose Cart-3
Multi-Purpose Cart
Multi-Purpose Cart-3
1600mm×800mm×1933 mm
Modular Drop Arm System
Lights Pole
Modular Drop Arm System
660×600×10mm
Double Layers T-Bar Lights Pole
Multi-Purpose Cart
Double Layers T-Bar Lights Pole
600mm×1000mmmm

Touring Truss | Multi-Scenario Efficient Stage Load-Bearing Frame

Widely applied in concert tours, music festivals, roadshows and brand launches. Modular quick-lock design enables fast assembly & disassembly. High-strength aluminum delivers stable load capacity with multi safety structures for frequent cross-venue touring.

Request a Wholesale Quote Today
Concerts
Concerts
Festivals
Festivals
Exhibitions
Exhibitions
Outdoor Events
Outdoor Events

Can't Find a Suitable Product?

Click to View Other Products!
Small Truss
Small Truss
100mm-305mm
Medium Truss
Medium Truss
400mm-529mm
Large Truss
Large Truss
600mm-1010mm

FAQ

Welcome to our FAQ, we are so happy to have you here and as a client.

We have tried to answer the most common questions.

Q
What aluminum alloy material do PR3 & PR5 Pre-Rig Truss adopt, and what is the main tube specification?
-
+

Both models are made of EN AW-6082 T6 aluminium alloy, main tube Φ50×4mm, vice tube Φ50×3mm, brace tube Φ25×3mm.

Q
What are the overall dimensions and net weight of PR3 and PR5 Pre-Rig Truss?
-
+

PR3 overall size:1524×609×356mm, weight 19.2kg; PR5 overall size:2400×609×356mm, weight 31kg. Base dimensions: PR3 1115×1302mm, PR5 1115×2178mm.

Q
What two main parts compose the pre-rig truss, and what function does the base provide?
-
+

It consists of truss section and wheeled transport base. The base with vertical supports and universal casters holds the whole truss and enables flexible venue transfer.

Q
What scenarios are Pre-Rig Truss suitable for, can they work with aluminium truss system?
-
+

Ideal for national commercial tours, music festivals, exhibitions and corporate conferences for pre-rig light transport. It can match lighting towers and roof truss to build integrated aluminum truss system.

Q
As professional truss manufacturers, do you support truss wholesale bulk orders for PR3 & PR5 Pre-Rig Truss?
-
+

We support large-volume truss wholesale for both models with sufficient stock. One-stop delivery is available matched with full series aluminium truss, lifting towers and light porters.
