F23-C21
Spigot Truss F23 Series Cross Sectional View

F23-C21 2-way 90° Corner Apex Out/Down

2-way 90° corner apex out/down


Length (L)0.5m (1.64ft)
Angle (A)2-way 90° corner apex out/down
Weight (W)2.1kgs(4.63lbs)


Advantages of F23-C21

Compact & Lightweight Design Compact & Lightweight Design
Compact & Lightweight Design
Features a slim 220 mm profile and resilient yet light aluminum construction.
Efficient Assembly Efficient Assembly
Efficient Assembly
Utilizes included conical connectors for quick, tool-free installation.
Strong Load Support Strong Load Support
Strong Load Support
Capable of spans up to 10 m, offering sturdy support for lightweight loads.
TÜV-Certified Safety TÜV-Certified Safety
TÜV-Certified Safety
Ensures precise alignment and quick assembly.
Customizable Aesthetics Customizable Aesthetics
Customizable Aesthetics
Available in any RAL powder-coated finish to suit design needs.
Perfect for Tight Spaces Perfect for Tight Spaces
Perfect for Tight Spaces
Especially useful in compact environments like retail displays or trade fair setups.

Loading Table of F23

Span(m)2m3m4m6m8m10m
Distrib.Load(kg/m)1751146427148
Deflection(mm)1.54.98.920.13656.8
Point Load(kg)262171127815641
Deflection(mm)1.847.216.53048.3


Products Associated with F23-C21

Corner Triangle Truss
/
Triangle Truss
/
Component
/
​F23-C19
Triangle Truss
​F23-C19
​2-Way 45° Corner
F23-C20
Triangle Truss
F23-C20
2-Way 60° Corner
​F23-C22
Triangle Truss
​F23-C22
​2-Way 120° Corner
​F23-C23
Triangle Truss
​F23-C23
​2-Way 135° Corner
​F23-C24
Triangle Truss
​F23-C24
​2-Way 90° Corner Apex Out
F23-C25
Triangle Truss
F23-C25
2-way 90° Corner Apex In
​F23-C31
Triangle Truss
​F23-C31
​3-way 90° Corner Apex Up Right
​F23-C32
Triangle Truss
​F23-C32
​3-Way 90° Corner Apex Up Left
F23
Triangle Truss
F23
220mm×195.2mm
F23 BP Male
Base Plate
F23 BP Male
220mm×195.2mm

Small Truss - Lightweight & Stable

Made of high-strength materials, lightweight, easy to assemble and stable in load-bearing. Suitable for exhibitions, stages, advertising, etc. Modular design for flexible size adjustment, wind-resistant and anti-deformation, practical and economical.

Request a Wholesale Quote Today
Acuivity Construction
Acuivity Construction
Building Assistance
Building Assistance
Equipment Support
Equipment Support
Decorative Structure
Decorative Structure

Can't Find a Suitable Product?

Click to View Other Products!

FAQ

Welcome to our FAQ, we are so happy to have you here and as a client.

We have tried to answer the most common questions.


Q
What aluminum alloy material is F23 triangular spigot truss made of, what are its tube and profile specifications?
-
+

It is made of high-strength aviation-grade EN AW-6082 T6 aluminum alloy. Main tube Φ35×2mm, brace Φ8mm, triangular profile size 195.2×220mm, a compact 220mm aluminium truss profile.

Q
What standard lengths are available for F23 truss, and what is the unit weight range?
-
+

Available standard lengths: 0.5m, 1m, 1.5m, 2m, 2.5m, 3m, 3.5m, 4m. Unit weight ranges from 2.2kg to 10.08kg, lightweight for easy carrying and stacking.

Q
What application scenarios fit F23 triangular aluminium truss, and what’s its maximum supporting span?
-
+

It fits light & medium duty structures including banner frames, retail display racks, exhibition booths, permanent lighting rigging and indoor decorative fixtures. Its maximum safe span reaches 10 meters, balancing functionality and elegant appearance.

Q
What connection structure does F23 spigot truss adopt, and are matching accessories complete?
-
+

It adopts integrated conical spigot bolt connection design. Full matching spigot connectors are included in each piece, enabling quick assembly without extra tools, to build complete aluminum truss system freely.

Q
As professional truss manufacturers, do you support truss wholesale of F23 aluminium truss?
-
+

We support large-volume truss wholesale with full sizes in stock. Custom special lengths and anodized surface colors are available on request, plus extended accessories like triangular corners and bases for matching.
