The HT32 series ladder truss is made of high-quality EN AW-6082 T6 aluminum alloy, which for high strength and durability. Featuring a 290mm specification profile and spigot connection, main tube dimension in 50*3mm and brace in 20*2mm, better strength for enhanced truss structure stability and load capacity. Its spigot connection system ensures quick and convenient assembly, making it ideal for large lighting rigging, special exhibition structures, large span project, and stage frameworks setups. Lightweight yet durable, with the advantage of easy handling, storage space saving and high transport efficiency.
SPECIFICATIONS
| Main tube | 50x3mm(2x0.12 inch) |
| Braces | 20x2mm(0.8x0.08 inch) |
| Alloy | EN-AW 6082-T6 |
HT32 STRAIGHT SEGMENT
| Span(m) | 2m | 3m | 4m | 6m | 8m | 10m | |||
| Distrib.Load(kg/m) | 710 | 254 | 115 | 64 | 40 | 27 | |||
| Deflection(mm) | 1.7 | 9.6 | 22.3 | 40.4 | 64.2 | 94.1 | |||
| Point Load(kg) | 1027 | 508 | 344 | 256 | 202 | 165 | |||
| Deflection(mm) | 1.9 | 7.7 | 18 | 32.8 | 52.5 | 77.5 | |||
1. Premium Material – Made from EN AW-6082 T6 aluminum for superior strength and corrosion resistance.
2. Standard 290mm Profile – Provides excellent stability for small to medium event structures.
3. Spigot Connection System – Enables fast, tool-free assembly and dismantling.
4. Lightweight and Portable – Easy to transport and handle for quick setups.
5. Versatile Applications – Ideal for lighting grids, exhibition booths, and decorative frameworks.
6. Modular Compatibility – Works seamlessly with other truss components in the same series.
