4-way 90° corner vertical
SPECIFICATIONS
| Length (L) | 0.5m (1.64ft) |
| Angle (A) | 4-way 90°corner vertical |
| Weight (W) | 4.4kgs(9.70lbs) |
F32 STRAIGHT SEGMENT
| Span(m) | 2m | 4m | 6m | 8m | 10m | 12m | |||
| Distrib.Load(kg/m) | 673 | 166 | 76 | 43 | 27 | 18 | |||
| Deflection(mm) | 2.3 | 9.3 | 21.9 | 39.8 | 63.7 | 94 | |||
| Point Load(kg) | 673 | 333 | 228 | 170 | 135 | 110 | |||
| Deflection(mm) | 1.9 | 7.4 | 17.6 | 32.3 | 52.5 | 77.7 | |||
