It adopts EN AW-6082 T6 aluminium alloy, main tube Φ50×2mm, brace tube Φ20×2mm, triangular cross-section 257.8×290mm.
-
- EN
-
3032&3035 F33 Female is a female-type floor base exclusively for the F33 triangular spigot aluminium truss series. It is integrally manufactured from high-strength alloy material with anti-corrosion and weather-resistant surface treatment. Three standard socket holes are arranged on the triangular plate, which can be accurately matched with the spigot end of the F33 truss and locked by pins. As the floor support component of vertical truss columns, it evenly transfers truss loads to the ground, effectively enhancing the overall structural stability of the tower and preventing tilting and displacement. It is suitable for various aluminum truss system construction scenarios such as indoor and outdoor performance truss towers, exhibition display frames and event backdrop frames, with plug-in connection for efficient assembly and disassembly, adaptable to various ground environments. Developed by professional truss manufacturers with original mold matching, it is fully compatible with all F33 series trusses and connector accessories, and supports truss wholesale bulk supply.
| Span(m) | 2m | 4m | 6m | 8m | 10m | 12m |
| Distrib.Load(kg/m) | 761 | 206 | 92 | 51 | 31 | 20 |
| Deflection(mm) | 2.6 | 11.5 | 26.8 | 48.8 | 75.2 | 105.6 |
| Point Load(kg) | 761 | 412 | 277 | 206 | 154 | 117 |
| Deflection(mm) | 2.1 | 9.3 | 21.7 | 39.8 | 62 | 88.3 |
Made of high-strength materials, lightweight, easy to assemble and stable in load-bearing. Suitable for exhibitions, stages, advertising, etc. Modular design for flexible size adjustment, wind-resistant and anti-deformation, practical and economical.
Welcome to our FAQ, we are so happy to have you here and as a client.
We have tried to answer the most common questions.
It adopts EN AW-6082 T6 aluminium alloy, main tube Φ50×2mm, brace tube Φ20×2mm, triangular cross-section 257.8×290mm.
Standard lengths: 0.5 / 1 / 1.5 / 2 / 2.5 / 3 / 3.5 / 4 / 4.5 / 5 m, maximum single length 5 m.
It includes various corners & cube joints: F33-C21, F33-C33, F33-C41, F33-C44, F33-C52, F33-C53; multi-way T-joints: F33-T35, F33-T39, F33-T42, F33-T43, F33-T45, F33-T51, F33-T61.
Ideal for medium-small music festivals, touring shows, exhibition booths, hotel banquet lighting and line array rigging. It can cooperate with lifting towers, manual & electric hoists to build integrated aluminium truss rigging system.
We support large-volume truss wholesale for complete F33 sets with standard sizes in stock. Custom non-standard lengths are available, with one-stop delivery matched with full series aluminium truss accessories, towers and hoists.
We are not only manufacturer of high quality stage truss, also we have professional R&D team and engineers for create solutions for your needs.
Provides standard trusses in various specifications and required length, structure design, touring truss, stage equipments and accessories, etc.
